Voltage Transformer (VT) Assembly Line Technical Specification
Core Components & Technologies
1. Conveying System
?
Precision Roller Conveyor/Dual-Speed Chain Conveyor
?
Positioning Tooling:
?
Mechanical limiters + vacuum adsorption
?
Workpiece positioning accuracy: ±0.1mm
2. Automated Winding Technology
?
Fully Automatic CNC Winding Machine:
?
Winding tension control (prevent breakage/slack)
?
Turn count error: ≤±1 turn
?
Servo motor + precision wire spreader
?
Wire types: Copper/Aluminum enameled wire
?
Real-time Monitoring:
?
Auto-binding of winding endpoints
3. Modular Adaptation System
?
Rapid Switch Tooling:
?
Supports 10kV/35kV/110kV voltage levels
?
Compatible with oil-immersed/dry-type structures
?
Program-Driven Parameter Switching:
?
Primary winding: Thick wire, few turns (e.g., 110kV: ?2.0mm, ≤50 turns)
?
Secondary winding: Thin wire, multiple turns (e.g., 100V output: ?0.5mm, 500+ turns)
